Paired Scatter Plot with Rotated Histogram Inset

Create a paired scatter plot with a rotated (-45 degree) difference histogram inset in the upper-right corner. Suitable for Control vs Treatment paired comparisons. Inspired by Cell journal figure style.

Usage

PlotScatter3(
  data,
  x = "Control",
  y = "Treat",
  group = "group",
  group_levels = NULL,
  highlight_color = "#f71d53",
  insig_border = NULL,
  point_shape = 21,
  point_size = 3,
  point_stroke = 0.8,
  xlab = "Control",
  ylab = "Treat",
  axis_limits = NULL,
  axis_breaks = NULL,
  show_refline = TRUE,
  test_method = "wilcox",
  p_digits = 2,
  p_size = 4,
  p_x = NULL,
  p_y = NULL,
  cor_method = "pearson",
  cor_size = 4,
  cor_x = NULL,
  cor_y = NULL,
  hist_bins = 30,
  hist_x_limits = NULL,
  hist_x_breaks = NULL,
  hist_border = NULL,
  median_label_size = 5,
  median_line_yend = NULL,
  inset_left = 0.6,
  inset_bottom = 0.6,
  inset_right = 1.1,
  inset_top = 1.1,
  inset_angle = -45,
  inset_vp_width = 0.85,
  inset_vp_height = 0.75,
  theme_use = theme_my(border = FALSE, panel.grid = ggplot2::element_blank()),
  plot_margin = c(80, 60, 5, 5),
  filename = NULL,
  width = 6,
  height = 6.5,
  dpi = 300,
  bg = "white"
)

Arguments

data: A data.frame containing x (control), y (treatment), and group columns.
x: Column name for control values (X axis). Default "Control".
y: Column name for treatment values (Y axis). Default "Treat".
group: Column name for significance grouping (must have 2 levels). Default "group".
group_levels: Character vector of length 2: c(insignificant, significant). NULL auto-detects from data.
highlight_color: Colour for the significant group. Default "#f71d53".
insig_border: Border colour for insignificant points. Default NULL (same as highlight_color).
point_shape: Point shape code. Default 21 (filled circle).
point_size: Point size. Default 3.
point_stroke: Point border width. Default 0.8.
xlab: X axis label. Default "Control".
ylab: Y axis label. Default "Treat".
axis_limits: Numeric vector of length 2 for axis range. Default NULL (auto: symmetric range from data).
axis_breaks: Numeric vector for axis tick positions. Default NULL (auto via pretty()).
show_refline: Whether to show reference lines (x=0, y=0, y=x). Default TRUE.
test_method: Paired test method: "wilcox", "t.test", or "none". Default "wilcox".
p_digits: Number of digits for p-value. Default 2.
p_size: Text size for p-value label. Default 4.
p_x, p_y: Coordinates for p-value label. Default NULL (auto).
cor_method: Correlation method: "pearson", "spearman", or "none". Default "pearson".
cor_size: Text size for correlation label. Default 4.
cor_x, cor_y: Coordinates for correlation label. Default NULL (auto).
hist_bins: Number of histogram bins. Default 30.
hist_x_limits: Histogram X axis range. Default NULL (auto).
hist_x_breaks: Histogram X axis ticks. Default NULL (auto).
hist_border: Histogram bar border colour. Default NULL (auto).
median_label_size: Text size for median label. Default 5.
median_line_yend: Height of median vertical line. Default NULL (auto).
inset_left, inset_bottom, inset_right, inset_top: Inset boundaries (patchwork coordinates). Default 0.6, 0.6, 1.1, 1.1.
inset_angle: Rotation angle for inset. Default -45.
inset_vp_width, inset_vp_height: Viewport size for inset. Default 0.85, 0.75.
theme_use: Theme function, string, or theme object. Default theme_my(border = FALSE, panel.grid = element_blank()).
plot_margin: Numeric vector of length 4 (top, right, bottom, left) for main plot margin. Default c(80, 60, 5, 5).
filename: Output file path. Default NULL (no save).
width: Output width in inches. Default 6.
height: Output height in inches. Default 6.5.
dpi: Output resolution. Default 300.
bg: Output background colour. Default "white".

Value

A patchwork object (combined plot).

Details

For single-group scatter with marginal boxplots, see [PlotScatter1()]. For dual-group scatter with marginal boxplots, see [PlotScatter2()].

Examples

library(ggplot2)

# Simulated paired data (Control vs Treatment)
set.seed(42)
n <- 80
ctrl <- rnorm(n, mean = 0, sd = 1)
treat <- ctrl + rnorm(n, mean = 0.3, sd = 0.5)
sig <- abs(treat - ctrl) > 0.5
df <- data.frame(
  Control = ctrl,
  Treat   = treat,
  group   = ifelse(sig, "Significant", "NS")
)

# Basic usage (auto axis, wilcoxon test, pearson correlation)
PlotScatter3(df)
#> Warning: Removed 4 rows containing missing values or values outside the scale range
#> (`geom_bar()`).
#> Warning: cannot clip to rotated viewport


# Custom highlight colour and t-test
PlotScatter3(df, highlight_color = "#2a5acb", test_method = "t.test")
#> Warning: Removed 4 rows containing missing values or values outside the scale range
#> (`geom_bar()`).
#> Warning: cannot clip to rotated viewport


# Spearman correlation, no reference lines
PlotScatter3(df, cor_method = "spearman", show_refline = FALSE)
#> Warning: Removed 4 rows containing missing values or values outside the scale range
#> (`geom_bar()`).
#> Warning: cannot clip to rotated viewport
